MVK1136P6
Bandpass
The Mavitek MVK series Bandpass Cavity filters in 6“ (152mm) diameter are designed and produced to meet the high selectivity. The MVK series filter are blue enamel painted copper. The connectors are silver-plated and PTFE insulated. With high “Q” values they achieve maximum isolation and superior performance with 500kHz Rx/Tx frequency shift.
Model No MVK1136P6
Electrical Specifications
Frequency Range 138-174 MHz
Maximum Input Power 300W
Insertion Loss Between 0.5 and 2.0dB
VSWR (max.) 1.5:1
Impedence 50Ω Nominal
Mechanical Specifications
Operating Temperature Range Between -30°C and +60°C
Number of Cavities 1 / 150mm (6 inch)
Connector Type N-Type Female
Color / Paint Blue / Glossy Enamel
Weight 3.5kg
Dimensions 150 x 640mm
