MVD4040
4 Cavity VHF Low Band Duplexer
Mavitek MVD serisi 4 kaviteli duplexer’lar, band pass/band reject konfigürasyonu ile 40-50MHz frekans bandında kullanılmak üzere üretilmiştir. Verici ve alıcı ünitenin aynı anda tek bir antenle çalışmasını minimum araya girme kaybı ve azami performansla sağlar.
İNDİR
İNDİR
| Model No | MVD4040 |
| Electrical Specifications | |
| Frequency Range | 40-50MHz |
| Minimum Frequency Separation | 275kHz |
| Maximum Input Power | 350W |
| Insertion Loss Tx/Rx to Ant. | 1.5dB (Adjustable) |
| VSWR (max.) | 1.5:1 |
| Rx Isolation at Tx Frequency | More than 80dB |
| Tx Isolation at Rx Frequency | More than 80dB |
| Impedence | 50Ω Nominal |
| Mechanical Specifications | |
| Operating Temperature Range | Between -30°C and +60°C |
| Dimensions | 440x2000x460mm |
| Weight | 60kg |
| Connector Type | N-Type Female |
| Color / Paint | Blue / Glossy Enamel |
| Number of Cavities | 4 / 200mm |
| Mounting | 19" Rack |
